B300K and AC500

[rwessels]

I have an AC500 with one B300S and two B300, can I add a B300K and will it work efficiently?

[Sideeffect]

Yes, but you will need the additional P090D To P150D cable if you connect it directly to the AC500 or B300S like you do with the B300. Depending on the firmware of the B300 you are either limited to 4 or 6 batteries, either way you will be fine with 4. When you go above 4 you need the B300 batteries to be within the first 4 batteries in the ordering.

Edit - That change from 4 - 6 batteries when using B300 batteries might be Apex 300 specific so take that with a pinch of salt. However with 4 batteries you will be fine.

[rwessels]

Thanks much! Where can I learn about the order of the batteries?

[Sideeffect]

There is some information here but it is Apex300 specific. I am not certain if these changes are backwards compatible with AC500.

How to connect Apex 300 to B300K/B300S/B300?

One Apex 300 can connect to up to 6×B300K/B300S/B300 batteries. You can also mix different battery types (B300, B300K, and B300S), with a total of up to 6 batteries. If your B300K is using the short cable, connect that one first, as the short cable should be closest to the Apex 300. Check the step-by-step guide to help you get set up quickly and easily. [BLUETTI Apex 300: Connecting Expansion Batteries]

And more information here about ordering but again this is Apex 300.

- YouTube

[sunrvr]

I have watched several review video’s of the Apex 300, I believe there is
a way to do it, but a specific cable/cord is necessary. Some of the reviews
have done comparisons with the AC units and I believe mentioned cord necessary to do so.
I have a “perk” reserved on IndieGoGo as a result of watching reviews.
